10/7 Concrete Mixer Without Hopper
10/7 Concrete Mixer Without Hopper is a widely used machine used in small construction work due to its steadiness and durability.
It is engrossed with ball bearings and gun metal bushes that help the machine to operate in a simple and smooth manner. This range offers an optimum mixing of cement and concrete giving high quality performance and durable finish standards.
COSMOS
Features
- High production
- Can easily shift from one place to another
- Designed with heavy duty, robust and balanced chassis
- Engrossed with heavy blade for homogenous mixing
- Require low power consumption
- Have longer functional life
- Durable finish standards
Technical Specifications
| Unit | 10/7 Concrete Mixer (without hopper) | |
| Drum capacity | Cubic feet/ Liters | 10/283 |
| Mixed | Cubic feet/ Liters | 7/198 |
| Drum speed | RPM | 18 |
| Prime mover | Diesel engine | 6 H.P. Air cooled |
| — | Electric motor | 5 H.P. 6 phase |
| Anti Vibration Pad | Nos | Optional |
| Transportation | Pneumatic Wheels | 4 |
| Skip Operation | — | NA |
| Drum | Mild steel or casting | — |
| Yoke | Mild steel or casting | MS/Casting |
| Wipe Drum Rope | Casting material | NA |
| Dimensions | L x W x H in meters | 2.9 x 2 x 1.5 |
